Schneider TSXETZ410 Ethernet Module – Industrial Networking for PLCs

Product Type:Module

Product ID:TSXETZ410

Schneider Type Designation:Extended

Product Classification:Ethernet module

Physical Interface:RJ45 10BASE-T/100BASE-TX

Transmission Rate:10/100 Mbit/s

Supply Voltage:24 V DC

Power Dissipation:2.4…4 W

Current Consumption:100 mA at 24 V DC, 50…200 mA at 24 V DC

Product Weight:0.62 lb (US) or 0.28 kg

Network Protocol Support:[“Ethernet TCP/IP”,”UNITE”,”Modbus messaging”,”BOOTP”]

Fault Tolerance Features:[“Bootloader”,”Diagnostic web server”]

Replacement Policy:Faulty Device Replacement (FDR)

    The Schneider TSXETZ410 Ethernet Module is specifically engineered to enhance the connectivity and efficiency of Schneider‘s Micro PLC systems, providing a robust solution for industrial automation networks.

    With its Ethernet TCP/IP compatibility and support for both 10/100 BaseTx and 56Kbps modem functionality, this module ensures reliable data transfer speeds essential for real-time industrial control applications.

    Equipped with UNITE and Modbus messaging, the TSXETZ410 enables seamless communication between various industrial devices, streamlining operations and enhancing productivity.

    Featuring advanced diagnostic capabilities through a web server, users can monitor and manage their system’s performance easily, including rack viewer, data editor, alarm viewer, and graphic editor functionalities.

    The modular design of the Schneider TSXETZ410 allows for flexible installation and expansion, making it a versatile choice for evolving industrial networking needs.
